RT10 Windows Specifications
Dimensions (W x L x H)
271.9 mm x 198.3 mm x 19.5 mm (10.7 in x 7.81 in x 0.77 in)
Weight
1.2 kg (2.65 lbs) with standard battery
1.4 kg (3.1 lbs) with extended battery
Operating Temperature
AC Power: -20°C to 60°C (-4°F to 140°F)
Battery Power: -10°C to 50°C (14°F to 122°F)
Storage Temperature
-30°C to 70°C (-22°F to 158°F)
Humidity
10% to 90% RH, non-condensing
Transit Drop
1.2 m (4 ft), MIL-STD-810G, Method 516.6, Procedure IV
Crash Shock
MIL-STD-810G, Method 516.6, Procedure V
Vibration
MIL-STD-810G, Method 514.6, Procedure I
Environmental Sealing
IP65
TPM
v2.0
Kensington Lock slot
Processor
Intel® Pentium® N4200 Apollo Lake Processor 1.10 GHz, up to 2.50 GHz with turbo
boost technology
Operating System
Windows® 10 IoT Enterprise (64-bit)
Memory
8 GB RAM, 128 GB Storage
Display
10.1-inch, 800 NIT brightness,
1920 x 1200 resolution
Optically bonded
Audio
Integrated microphone with noise cancellation
Dual 1W speakers
I/O Ports
1x Micro HDMI
1x USB 3.0 (Type A)
1x USB 3.0 (Type C)
1x 3.5mm Audio Combo Connector (Mic in or line out)
1x DC jack
1x Micro SDXC slot
Keys
1x Power
1x Home
2x Programmable function keys
Volume control
Camera
Rear: 8 MP autofocus with flash
Front: 2 MP
Sensors
Ambient light sensor, accelerometer, gyroscope
Battery
Standard: 5,900 mAh, approximately 8 hours operating time
Extended: 10,280 mAh, approximately 16 hours operating time
Bridge battery for hot-swapping capability
Scanning Capabilities
Honeywell N6703 Standard Range 1D/2D Imager
Honeywell FlexRange 1D/2D Imager
WLAN
802.11 a/b/g/n/ac
WWAN
4G LTE
Bluetooth
Bluetooth® V5.0
3-year
limited factory warranty
RT10
Android Specifications
Dimensions (W x L x H)
271.9 mm x 198.3 mm x 19.5 mm (10.7 in x 7.81 in x 0.77 in)
Weight
1.2 kg (2.65 lbs) with standard battery 1.4 kg (3.1 lbs) with extended battery
Operating Temperature
AC Power: -20°C to 60°C (-4°F to 140°F)
Battery Power: -10°C to 50°C (14°F to 122°F)
Storage Temperature
-30°C to 70°C (-22°F to 158°F)
Humidity
10% to 90% RH, non-condensing
Transit Drop
1.2m (4 ft), MIL-STD-810G, Method 516.6, Procedure IV
Crash Shock
MIL-STD-810G, Method 516.6, Procedure V
Vibration
MIL-STD-810G, Method 514.6, Procedure I
Environmental Sealing
IP65
WLAN Security
OPEN, WEP, WPA/WPA2 (Personal and Enterprise)
Kensington Lock slot
Processor
2.2 GHz Qualcomm® 64-bit Snapdragon™ octa-core
Operating System
Android P, upgradable through Android R
Memory
4 GB RAM, 32 GB Storage
Display
10.1-inch, 800 NIT brightness,
1920 x 1200 resolution
Optically bonded
Audio
Integrated microphones with noise cancellation
Dual 1W speakers
I/O Ports
1x USB 3.0 (Type A)
1x USB 3.0 (Type C)
1x 3.5mm Audio Combo Connector (Mic in or line out)
1x DC jack
1x Micro SDXC slot
User-accessible microSD: Card up to 512 GB (SDXC/SDHC/ SDIOcompliant)
Keys
1x Power
1x Home
2x Programmable function keys
Volume control
Camera
Rear: 13 MP autofocus with flash
Front: 8 MP
Sensors
Ambient light sensor, accelerometer, gyroscope
Battery
Standard: 5,900 mAh
Extended: 10,280 mAh
Hot-swap battery capability
Scanning Capabilities
Honeywell N6703 Standard Range 1D/2D Imager
Honeywell FlexRange 1D/2D Imager
WLAN
IEEE 802.11 a/b/g/n/ac; Wi-Fi certified 2x2 MIMO support
Additional WLAN Features
802.11 d/e/h/i/k/r/w
WLAN Security
OPEN, WEP,WPA/WPA2 (Personal and Enterprise)
WWAN
WWAN: WWAN Radio (ATT/VZW/ NA/EU) LTE Advanced Support
Up to 400 Mbps CAT13 LTE downlink
Up to 75 Mbps CAT5 LTE uplink LTE (FDD) – ands 1, 2, 3, 4, 5, 7, 8, 12,13,17,
19, 20, 25, 26, 28, 29 LTE (TDD) – Bands 38, 39, 40, 41
UMTS/HSPA+ (3G) – Bands 1, 2, 4, 5, 6, 8, 9, 19
GSM/GPRS/EDGE Quad-Band (850/900/1800/1900 MHz) 1xRTT/EV-DO – Bands BC0, BC1,
BC10 (B26BW)
Bluetooth®
V5.0 Bluetooth and BLE Supported Bluetooth Profiles: HFP, PBAP, A2DP,
AVRCP,OPP, SPP, GATT
NFC
Integrated Near Field Communication
Push to Talk (PTT): Supported
GPS Supported Protocols: Simultaneous
GNSS. Receiver Support for GPS, GLONASS, Galileo, and Beidou
3-year
limited factory warranty
